FD-35W, Professional Peltier Air Conditioner

FOB Reference Price:Get Latest Price
$39.00 - $50.00 / Piece | 1 Piece/Pieces (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Mounting:
Other
Place of Origin:
Guangdong, China
Brand Name:
FuDi
Model Number:
FD-35W
Certification:
RoHS
Operating Voltage:
DC12V
Condition:
New
Cooling Capacity:
35W
voltage:
DC12V
Current:
4A
Operating Temp:
-10℃--+70℃
Weight:
1.2 Kg
After-sales Service Provided:
Engineers available to service machinery overseas
Type:
Portable Air Cooler
Packaging & Delivery
Packaging Details
Carton box or Customized
Port
Shenzhen, HongKong, Guangzhou
Lead Time :
Depends on Qty

Advantages:

  • Our R&D team has been working in this industry more than 20 years.
  • The products perform steady, efficient and long-span.



Applications:

Thermoelectric cooler is widely used for air-conditioning in enclosed area. Such as telecom outdoor cabinet, battery cabinet, industry control cabinet, precision instrument, telecommunication parts, medicine equipment, military equipment, and etc.



Working principle:

Thermoelectric cooler is cooling equipment consists of semi-conductor.The inner sealed circuit is composed of the two different metal traverses X and Y.



After it is powered,heat on cool end is transferred to hot end,which leads to the temperature drop of cool end and temperature rise of hot end.And switch between hot end and cool end can be completed by changing electrode.


Specification:
Item (Th=35C)Description
Hot sideFan cooling
Cold sideFan cooling
Qc max(W)35W dT=0C
Rated voltage12V 3.5A
Working Temp.-10~+70C
Temp. ControlOptional

Part List:
No.PartDescriptionQTY
1InputDC 12V, 4A1
2TEM40*40*4.1mm, Qmax=40W1
3Inside fan60*60*25mm, 12VDC1
4Outside fan92*92*25mm, 12VDC1
5Cold sink63*100*25mm, AL1
6Heat sink100*150*30mm, AL1
7Space block32*32*5mm, AL1
8Thermostat7*3.5*18.5, 80C1
9Bolt+WasherM4 SUS Wrench bolt+Spring wahser+Plat washer+Insulation washer2
